USB 3.1 Interface Module
SKU
Q
Super speed “USB 3.1 type C modules” for RF Test Enclosures eliminate conducted and radiated interference while keeping data and power signals for USB 3.1 link untouched.
Features:
- Filtered SuperSpeed data interface for USB 3.1 Gen .1 Type C
- Fully compliant with USB 3.0, 2.0, and USB 1.0
- Utilizes Microwave resonator techniques to differentiate between wanted USBsignals and unwanted interference
- Minimized attenuation to less than 3 dB on USB data signals
- 80 dB* isolation for a wide frequency range of 300 MHz – 13 GHz
- Ruggedized machined Aluminum casing requires mounting on I/O panel
- Compatible with any dbSAFE Series test enclosures or walk-in chambers
SKU
Q
Manufacturer
DVTEST
Connector Type
USB 3.1 Gen 1 Type C-C female
DC Line Impedance
0.1 Ω
Construction
Milled Aluminium 6061 Alloy – Machined per Precision
Compatibility
USB 3.0, USB 2.0, USB 1.1
Temperature
-20°C to 50°C
Balanced Data Line Impedance
90 Ω Differential
DC Power Handling
20V with 1A
External Dimensions (WxDxH)
2" x 3.15" x 1"
