dbDIRECT Broadband QRBH Antenna
SKU
099170
Broad frequency range, ideal for complementing RF test enclosures in various test setups
Application:
- RF wireless device testing in Anechoic chambers where directional and high gain link required with DUT
- 3G, 4G, 5G and 5G new radio (5G NR), Carrier aggregation, MIMO
- LTE, LTE-A, WiMAX, WiFi, Bluetooth, GPS, GSM, Z-Wave, LoRa
- Spectrum Analysis in DAS environment, radars, IoT
SKU
099170
Manufacturer
DVTEST
Frequency Range
300 MHz - 6 GHz
Maximum Input Power
500 W
Maximum Continuous Power
300 W
Connector Type
Stainless Steel 50Ω N Type, Female
Polarization
Dual Polarized, Linear
Gain
3 dBi - 14 dBi
External Dimensions (WxDxH)
19.96" x 20.08" x 19.96"
