dbSAFE ARMOR
SKU
dbSAFE ARMOR
Advanced Reconfigurable Modular OTA RF Test Enclosures,
≥100 dB isolation, 300 MHz - 90 GHz
The dbSAFE ARMOR series of shielded boxes are cost-effective solutions for OTA testing in the mmWave spectrum. Providing a shielded, fully anechoic test environment, these RF test enclosures ensure stable and repeatable measurements over a wide frequency range (from 300 MHz to 90 GHz).
DVTEST’s advanced double-wall technology and the resulting high isolation level make them suitable for testing 5G applications such as low-frequency devices (below 1 GHz), LTE-AP, 5G-NR, and mmWave (FR1 and FR2).
The dbSAFE ARMOR series shield boxes can include racking options to incorporate instruments directly at the enclosure – minimizing path loss and ensuring you get the best results.
Frequently Bought Together
Ideal for applications from 700 MHz to 18 GHz
50 MHz to 18 GHz Power Sensor - 5G OTA verification tools
Manufacturer
DVTEST
Shielding Effectiveness (dB)
300 MHz - 40 GHz ≥ 100 dB, 40 GHz - 90 GHz ≥ 90 dB
Chassis Type
Double Wall Welded Aluminium Structure
Surface Treatment
Tri-Shield© coated to MIL-DTL-5541F
Loading Style
Front
Base type
Extruded Aluminium Trolley
RF Gasket
Triple Layer Braid Over Foam
Absorber
High Performance, High Density 2.25” Pyramidal Absorber (Other absorber styles available, consult factory)
Internal Dimensions (WxDxH)
52" x 42" x 42"
External Dimensions (WxDxH)
60" x 50" x 50"
Warranty
3 Years
